斗山零件查询CONTROL VALVE - BOOM SWING E57W Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
554 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
410105-00845B
|
[1] |
|
|
| 1. |
K9005314
|
[8] |
NUT
|
|
| 10. |
100201-02904
|
[1] |
|
|
| 10-10. |
K9005491
|
[1] |
PLUG
|
|
| 10-11. |
K9005482
|
[1] |
O-RING
|
|
| 10-3. |
110910-01059
|
[2] |
|
|
| 10-7. |
K9005483
|
[1] |
POPPET
|
|
| 10-9. |
K9005484
|
[1] |
SPRING
|
|
| 11. |
100201-02903
|
[1] |
|
|
| 11-10. |
K9005491
|
[1] |
PLUG
|
|
| 11-11. |
K9005482
|
[1] |
O-RING
|
|
| 11-14. |
S8010700
|
[1] |
O-RING
|
|
| 11-3. |
110910-01059
|
[2] |
|
|
| 11-7. |
K9005483
|
[1] |
POPPET
|
|
| 11-9. |
K9005484
|
[1] |
SPRING
|
|
| 12. |
K9005979
|
[1] |
BLOCK ASS'Y-BOOM SWING
|
|
| 12-10. |
K9005491
|
[1] |
PLUG
|
|
| 12-11. |
K9005482
|
[1] |
O-RING
|
|
| 12-14. |
S8010700
|
[1] |
O-RING
|
|
| 12-3. |
110910-01059
|
[2] |
|
|
| 12-7. |
K9005483
|
[1] |
POPPET
|
|
| 12-9. |
K9005484
|
[1] |
SPRING
|
|
| 13. |
100201-02905
|
[1] |
|
|
| 13-10. |
K9005491
|
[1] |
PLUG
|
|
| 13-11. |
K9005482
|
[1] |
O-RING
|
|
| 13-14. |
S8010700
|
[1] |
O-RING
|
|
| 13-3. |
110910-01059
|
[2] |
|
|
| 13-7. |
K9005483
|
[1] |
POPPET
|
|
| 13-9. |
K9005484
|
[1] |
SPRING
|
|
| 14. |
K9005319A
|
[1] |
BLOCK ASS'Y-STRAIGHT TRAVEL
|
|
| 14-11. |
K9005487
|
[1] |
PLUG
|
|
| 14-12. |
K9005482
|
[1] |
O-RING
|
|
| 14-15. |
S8010700
|
[1] |
O-RING
|
|
| 14-3. |
110910-01062
|
[1] |
|
|
| 14-8. |
110910-01063
|
[1] |
|
|
| 15. |
410127-00427
|
[2] |
|
|
| 17. |
410127-00429
|
[8] |
|
|
| 18. |
K9005659
|
[1] |
VALVE;SHUT OFF
|
|
| 2. |
K9005330
|
[4] |
TIE-ROD
|
|
| 23. |
410127-00428
|
[1] |
|
|
| 3. |
100201-02897
|
[1] |
|
|
| 3-10. |
K9005487
|
[2] |
PLUG
|
|
| 3-11. |
K9005482
|
[2] |
O-RING
|
|
| 3-3. |
110910-01059
|
[2] |
|
|
| 3-7. |
K9005483
|
[1] |
POPPET
|
|
| 3-8. |
110938-00038
|
[1] |
|
|
| 3-9. |
K9005484
|
[2] |
SPRING
|
|
| 4. |
100201-02898
|
[1] |
|
|
| 4-10. |
K9005487
|
[2] |
PLUG
|
|
| 4-11. |
K9005482
|
[2] |
O-RING
|
|
| 4-14. |
S8010700
|
[1] |
O-RING
|
|
| 4-3. |
110910-01059
|
[3] |
|
|
| 4-7. |
K9005483
|
[1] |
POPPET
|
|
| 4-8. |
110938-00037
|
[1] |
|
|
| 4-9. |
K9005484
|
[2] |
SPRING
|
|
| 5. |
100201-02899
|
[1] |
|
|
| 5-10. |
K9005487
|
[1] |
PLUG
|
|
| 5-11. |
K9005482
|
[1] |
O-RING
|
|
| 5-12. |
S8010700
|
[1] |
O-RING
|
|
| 5-13. |
K9005485
|
[2] |
O-RING
|
|
| 5-20. |
S2205671
|
[5] |
BOLT;SOCKET
|
|
| 5-21. |
181-00561
|
[2] |
PLUG ASS`Y
|
|
| 5-3. |
110910-01059
|
[1] |
|
|
| 5-7. |
K9005486
|
[1] |
VALVE;ANTI-DRIFT
|
|
| 5-8. |
K9005483
|
[1] |
POPPET
|
|
| 5-9. |
K9005484
|
[1] |
SPRING
|
|
| 6. |
100201-02900
|
[1] |
|
|
| 6-11. |
S8010700
|
[1] |
O-RING
|
|
| 6-3. |
110910-01059
|
[2] |
|
|
| 6-7. |
K9005487
|
[1] |
PLUG
|
|
| 6-8. |
K9005482
|
[1] |
O-RING
|
|
| 7. |
K9005839
|
[1] |
BLOCK ASS'Y-INLET
|
|
| 7-3. |
110910-01060
|
[1] |
|
|
| 7-5. |
110910-01061
|
[1] |
|
|
| 7-7. |
S8010700
|
[2] |
O-RING
|
|
| 7-9. |
K9004467
|
[1] |
PLUG
|
|
| 8. |
100201-02901
|
[1] |
|
|
| 8-11. |
S8010700
|
[1] |
O-RING
|
|
| 8-3. |
110910-01059
|
[2] |
|
|
| 8-7. |
K9005487
|
[1] |
PLUG
|
|
| 8-8. |
K9005482
|
[1] |
O-RING
|
|
| 9. |
100201-02902
|
[1] |
|
|
| 9-10. |
K9005491
|
[1] |
PLUG
|
|
| 9-11. |
K9005482
|
[1] |
O-RING
|
|
| 9-14. |
S8010700
|
[1] |
O-RING
|
|
| 9-19. |
S8000105
|
[1] |
O-RING P10
|
|
| 9-21. |
S8000205
|
[1] |
O-RING
|
|
| 9-3. |
110910-01059
|
[2] |
|
|
| 9-7. |
K9005483
|
[1] |
POPPET
|
|
| 9-9. |
K9005484
|
[1] |
SPRING
|
|
