神钢零件查询(F4HFE413X B001) - ENGINE 5801910272 47446986 GRAPE HARVESTER 9050M / 9050 L T4B (10/14-12/15) (10.304.AJ) - OIL FILLER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
118 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | 4895406 | [1] | EXPANSION PLUG,9.8mm OD | TOR |
| 4. | 4897330 | [2] | HEX SOCKET PLUG,M12 x 1.5 | TORASSY, Incl 5, 6 |
| 5. | NSS | [2] | NOT SOLD SEPARAT | CONPlug, Incl in 4 |
| 6. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 7. | 4895037 | [1] | EXPANSION PLUG,32.03mm | TOR |
| 8. | 4898502 | [1] | O-RING,0.364" ID x 0.504" OD x 0.07" | LEC Superseded by part number: 17277981 |
