纽荷兰零件查询(DC80) - CRAWLER DOZER (N.A. VERSION) (4/99-) (0.520[01C]) - THROTTLE CONTROL (DC80 STD S/N 13141055 & DOWN; LGP S/N 13145015 & DOWN) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
506 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76590910 | [1] | KNOB | MAC |
| 2. | 76593028 | [2] | ARTICULATION | MAC Superseded by part number: 154104301 |
| 3. | 76592831 | [1] | CABLE | MAC |
| 4. | 76593027 | [1] | LEVER | MAC- ACCELERATORE |
| 5. | 76593026 | [1] | TIE-ROD | MAC |
| 6. | 76590915 | [1] | NUT | MAC- SELF-LOCKING Superseded by part number: 12577321 |
| 7. | 76590916 | [1] | POTENTIOMETER | MAC |
| 8. | 76590917 | [2] | LOCK WASHER | MAC |
| 9. | 76590918 | [2] | SCREW | MAC Superseded by part number: 300806 |
| 10. | 76590919 | [1] | WASHER | MAC Superseded by part number: 14496804 |
| 11. | 76590920 | [2] | SPRING | MAC |
| 12. | 76590921 | [1] | SLEEVE | MAC |
| 13. | 76590719 | [2] | SCREW | MAC Superseded by part number: 9706704 |
| 14. | 76590923 | [1] | WASHER | MAC |
| 15. | 76593029 | [1] | SUPPORT | MAC |
| 19. | 76590928 | [1] | SCREW | MAC Superseded by part number: 16043824 |
| 20. | 76590929 | [1] | NUT | MAC Superseded by part number: 43362 |
| 23. | 76590872 | [2] | SCREW | MAC Superseded by part number: 120100 |
| 24. | 76590873 | [2] | WASHER | MAC Superseded by part number: 10519404 |
| 25. | 76590934 | [2] | NUT | MAC- SELF-LOCKING Superseded by part number: 12574221 |
| 26. | 76592869 | [1] | SUPPORT | MAC |
| 27. | 76593095 | [1] | SUPPORT | MAC |
| 29. | 76595963 | [2] | GASKET | MAC Superseded by part number: 76590727 |
| 30. | 76591115 | [2] | SCREW | MAC Superseded by part number: 11112224 |
