神钢零件查询(F4HFE413Y B001) - ENGINE 5801910277 47446991 GRAPE HARVESTER 7030/7030L/8030L T4B (5/14-12/15) (10.400.AE) - COOLANT HEATING LINES Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
254 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TORASSY, Incl 11 - 12, Inlet |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 11 |
| 3. | 4895625 | [1] | O-RING,13.3mm ID x 2.2mm Width | TOR Superseded by part number: 17281681 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 14 |
| 5. | 4895080 | [2] | HEX SOCKET PLUG,M22 x 1.5 | TORASSY, Incl 13, 15 |
| 6. | 4895082 | [2] | O-RING,19.3mm ID x 2.2mm Width | TORID = 19.3 x 2.2 Superseded by part number: 2854072 |
| 7. | 4893036 | [1] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 7. | 2854866 | [1] | HEX SOCKET PLUG,3/4"-14 NPTF | TORAlternative Superseded by part number: 4893036 |
| 8. | 4895078 | [3] | PIPE PLUG,1/2"-14 | TOR |
