凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (02-048) - DE-CLUTCH LINKAGE ASSEMBLY S.N. CFH0156400 AND LATER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
369 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700135551
|
[1] |
SUPPORT
|
HFI
WA
|
| 2. |
700708652
|
[2] |
CLEVIS PIN
|
HFI
1/2 x 1-27/64" Superseded by part number: 427-8150
|
| 3. |
432-1016
|
[2] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 4. |
66183
|
[1] |
SHAFT
|
NNA
Superseded by part number: 066183
|
| 5. |
241-1316
|
[1] |
LINK,19.05mm Pitch
|
CAS
connector, #60 R/C
|
| 6. |
611362R91
|
[1] |
CHAIN (AG)
|
IH
roller, #60 (10 foot bulk) Superseded by part number: 611362R91X
|
| 7. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 8. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 9. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 10. |
700135561
|
[1] |
LEVER
|
HFI
WA
|
| 11. |
230-4118
|
[1] |
LOCK NUT,1/2"-13, GA
|
CAS
hex top lock, 1/2-13 GR/B
|
| 12. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2
|
| 13. |
858027
|
[1] |
COMPRESSION SPRING
|
CAS
|
| 14. |
700132453
|
[1] |
CLEVIS
|
HFI
|
| 15. |
425-108
|
[3] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 16. |
483-1316
|
[1] |
SET SCREW,Hex Soc, 5/16"-18 x 3/8"
|
CAS
cup point hex socket set, 5/16-18 x 3/8 NP
|
| 17. |
700135187
|
[1] |
COLLAR
|
HFI
|
| 18. |
700135549
|
[1] |
ROD
|
HFI
|
| 19. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 20. |
700135557
|
[1] |
LEVER
|
HFI
WA
|
