纽荷兰零件查询(DC80) - CRAWLER DOZER (N.A. VERSION) (4/99-) (4.340[01B]) - SALT CHAIN - SHOES (L=508 MM) DC80 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
807 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76590777 | [2] | SUPPORT | MACCarrier Roller |
| 2. | 76590728 | [4] | WASHER | MAC Superseded by part number: 895-11012 |
| 3. | 76590744 | [4] | NUT | MAC- SELF-LOCKING Superseded by part number: 12577521 |
| 4. | 76590780 | [2] | ROLLER | MACCarrier- ASSY. SEE SGR - 2.347 - TAV. 1 |
| 5. | 76590781 | [8] | SCREW | MAC Superseded by part number: 615-12035 |
| 6. | 76595963 | [8] | GASKET | MAC Superseded by part number: 76590727 |
| 8. | 76590783 | [4] | SCREW | MAC Superseded by part number: 86562594 |
| 9. | 76590784 | [4] | SCREW | MAC |
| 10. | 76590785 | [152] | SCREW | MAC |
| 11. | 76590786 | [2] | CONNECTING LINK | MACMaster; One Side Of Link Only; Use With 76590787 |
| 12. | 76590787 | [2] | TRACK LINK | MACMaster; One Side Of Link Only; Use With 76590786 |
| 13. | 76590788 | [152] | NUT | MAC |
| 14. | 76593032 | [1] | KIT | MAC Superseded by part number: 79086902, 75128769, 75128768, 75128766, 75128767 |
| 15. | 76595962 | [48] | SCREW | MAC Superseded by part number: 76592919 |
| 16. | 76605863 | [48] | LOCK WASHER | MAC Superseded by part number: 11198673 |
| 17. | 76590791 | [8] | TRACK ROLLER | MACSingle Flange |
| 18. | 76590792 | [4] | TRACK ROLLER | MACDouble Flange |
| 19. | 76590793 | [2] | IDLER | MACFront Idler |
| 20. | 76598272 | [46] | LOCK WASHER | MAC |
| 21. | 76593022 | [24] | SCREW | MAC Superseded by part number: 14429421 |
| 22. | 76593257 | [2] | SPROCKET | MACMounting Adapter Ring |
| 24. | 76592918 | [46] | SCREW | MAC |
| 25. | 76593264 | [1] | CHAIN | MACAssy. |
| 26. | 76592738 | [1] | CHAIN | MACTrack Assy. with Pads |
| 27. | 76590801 | [1] | TRACK SHOE | MACMaster Pad |
| 28. | 76590802 | [38] | TRACK SHOE | MACTrack Pad |
| 29. | 76592916 | [24] | LOCK WASHER | MAC |
| 30. | 76595964 | [50] | BOLT | MAC Superseded by part number: 76592915 |
| 31. | 76590796 | [2] | DRIVING SPROCKET | MACSegment; 5 Pieces Each Side |
| 32. | 76592914 | [78] | PLUG | MAC Superseded by part number: 79086902 |
