纽荷兰零件查询(DC80) - CRAWLER DOZER (N.A. VERSION) (4/99-) (4.346[01B]) - TRACK IDLER DC80 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
983 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76590793 | [2] | IDLER | MACWHEEL, IDLER ASSY. - INCLUDES REFS. 2 - 11 |
| 2. | 76590814 | [1] | WHEEL | MACIDLER - COMPLETE WITH "U" BRACKET |
| 3. | 76590815 | [1] | SPRING | MACSHOCK ABSORBER |
| 4. | 76590816 | [1] | WHEEL ASSY | MACWHEEL, IDLER W/MOUNTING BRACKET - FOR SERVICING THE WHEEL ONLY |
| 5. | 76590817 | [1] | WHEEL ASSY | MACWHEEL, IDLER W/O MOUNTING BRACKET - FOR SERVICING THE WHEEL ONLY |
| 6. | 76590818 | [2] | SEAL KIT | MACBUSHING Superseded by part number: 71401161 |
| 7. | 76590819 | [1] | GASKET | MACSEAL |
| 8. | 76590820 | [1] | GASKET | MAC |
| 9. | 76593603 | [1] | HYDRAULIC VALVE | MACVALVE, HYDRAULIC Superseded by part number: 76594911 |
| 10. | 76593604 | [1] | LUBE NIPPLE | MACNIPPLE, LUBE |
| 11. | 76593605 | [1] | WASHER | MAC |
