神钢零件查询(F4HFE6131 A005) - ENGINE 5801425077 - 84387924 (1/11-) (10.106.02) - ROCKSHAFT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
247 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895432 | [5] | SCREW,M8 x 1.25 x 70mm | TORM8 x 1,25 x 70 |
| 2. | NS | [6] | NOT SERVICED | BAS |
| 3. | 2859464 | [2] | RETAINER,10.79mm ID, 7.63mm ID | TOR Superseded by part number: |
| 5. | 2859461 | [1] | ROCKER ARM | TORASSY |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONASSY |
| 7. | 2859467 | [2] | NUT,Hex, 3/8" - 24, RH | TOR Superseded by part number: |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONASSY |
| 9. | 2859468 | [2] | ADJUSTMENT SCREW,3/8" - 24 x 23.85mm | TOR Superseded by part number: |
| 10. | 2859470 | [2] | SOCKET | TOR |
| 11. | 17094601 | [3] | WASHER | TOR Superseded by part number: 17094614 |
| 12. | 2852428 | [6] | WIRE CLAMP,6mm ID | TOR Superseded by part number: 504066132 |
| 13. | 2859462 | [1] | ROCKER ARM | TORASSY |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONASSY |
| 15. | 4899245 | [5] | SLEEVE,9mm ID x 13.9mm OD x 55.25mm L | TOR |
| 16. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 17. | 4899257 | [1] | HOUSING | TORASSY |
| 18. | 504039152 | [3] | ELECTRIC CABLE | SM Superseded by part number: 5801567608 |
| 19. | 2856460 | [2] | BOLT,Flng, M8 x 1.25 x 55.5mm, Cl 10.9 | TOR |
| 20. | 2859463 | [1] | SUPPORT | TOR Superseded by part number: |
| 21. | 4895031 | [12] | PUSH ROD | TOR |
| 22. | 2854530 | [12] | BRIDGE | SM Superseded by part number: 504085415 |
| 23. | 504070040 | [1] | GASKET | TOR Superseded by part number: 2853788 |
| 24. | 16689121 | [3] | SCREW,Skt Hd, M6 x 16mm | TOR Superseded by part number: 4895427 |
| 25. | 4899089 | [2] | SCREW,Hex Flg, M8 x 1.25 x 50 | TOR |
| 26. | NS | [2] | NOT SERVICED | BAS |
