纽荷兰零件查询(DC80) - CRAWLER DOZER (N.A. VERSION) (4/99-) (3.443[01C]) - LIFT CYLINDERS DC80 FROM S/N 13141001 - S/N 13141055,LGP FROM S/N 13145015 & DOWN New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
155 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | CYLINDER | [2] | CYLINDER | NHASSY. Superseded by part number: 76592857 |
| 2. | 76591112 | [1] | LUBE NIPPLE | MACGREASE FITTING |
| 3. | 76593246 | [1] | BARREL | MACCYL. TUBE |
| 4. | 76591221 | [2] | SLEEVE | MACBUSHING |
| 5. | 76591222 | [1] | SCREW | MAC |
| 6. | 76591223 | [1] | PISTON | MAC |
| 11. | 76591228 | [1] | BASE PLATE | MACBUSHING GUIDE |
| 16. | 76592858 | [1] | ROD | MACCYL. ROD |
| 17. | 76591234 | [1] | SEAL KIT | MAC Superseded by part number: V282183, U282182, 8210196, 8207696, 8207016, 8204583, 8204581, 1422270 |
| 18. | 76598253 | [1] | LUBE NIPPLE | MACGREASE FITTING Superseded by part number: 13408411 |
