神钢零件查询(F4HFE6131 A005) - ENGINE 5801425077 - 84387924 (1/11-) (10.218.03) - INJECTION PIPE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
325 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2854540 | [1] | MANIFOLD | TORASSY Superseded by part number: |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 3. | 504088436 | [1] | VALVE PRESSURE RELIE | TOR Superseded by part number: 42562997 |
| 4. | 2854542 | [1] | SENSOR,FUEL PRESSURE TO THE MANIFOLD | TOR Superseded by part number: |
| 5. | 2857017 | [3] | PIPE | TOR Superseded by part number: |
| 6. | 2857046 | [3] | PIPE | TOR Superseded by part number: |
| 7. | 2857048 | [1] | PIPE | TORASSY Superseded by part number: |
| 12. | 2853537 | [4] | BOLT,Hex Flange Head Cap M8 x 1.25 x 125mm | TOR Superseded by part number: 504053874 |
