凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (08-028) - HYDR. CYL. ASSY. (UPPER BALE TENSION) (2 IN. BORE X 12 IN. STROKE) (S.N. CFH0156001 THRU CFH0156399) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
880 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700719660
|
[1] |
CYLINDER
|
HFI
HYDRAULIC ASM. COMPLETE (2 inch bore x 12 inch stroke)
|
| 2. |
700707418
|
[1] |
JAM NUT
|
CAS
hex jam, 7/8-14
|
| 3. |
700707419
|
[1] |
PISTON
|
CAS
|
| 4. |
700711112
|
[1] |
GUIDE
|
CAS
ROD
|
| 5. |
700719662
|
[1] |
PISTON ROD
|
HFI
|
| 6. |
700711954
|
[1] |
SEAL KIT
|
CAS
KIT and O-ring repair, includes items in art marked with asterisk
|
