凯斯零件查询(RS561) - CASE IH ROUND BALER (1/99-12/00) (08-040) - HYDRAULIC CYLINDER ASSEMBLY (CLUTCH) (2 INCH BORE X 4 INCH STROKE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
822 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700711910
|
[1] |
CYLINDER ASSY.
|
IH
HYDRAULIC COMPLETE (2 inch bore x 4 inch stroke)
|
| 2. |
700707418
|
[1] |
JAM NUT
|
CAS
hex jam, 7/8-14 UNF
|
| 3. |
700707419
|
[1] |
PISTON
|
CAS
|
| 4. |
700711955
|
[1] |
PISTON ROD
|
CAS
|
| 5. |
700711112
|
[1] |
GUIDE
|
CAS
ROD
|
| 6. |
700711114
|
[1] |
SEAL KIT
|
L
seal and O-ring repair, includes items in art marked with asterisk
|
