纽荷兰零件查询(DC80) - CRAWLER DOZER (N.A. VERSION) (4/99-) (9.550[01B]) - TRACK ROLLER GUARD DC80 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
675 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76605607 | [2] | SHIELD | MACL.H. |
| 2. | 76595959 | [4] | NUT | MAC Superseded by part number: 12577721 |
| 3. | 76605604 | [8] | WASHER | MACWasher |
| 4. | 76605603 | [4] | THREADED TIE-ROD | MACTie Rod |
| 5. | 76605608 | [4] | SPACER | MACSpacer |
| 6. | 76605609 | [16] | PAD | MACBlock |
| 7. | 76605610 | [2] | SHIELD | MACR.H. |
| 8. | 76590722 | [16] | SCREW | MAC Superseded by part number: 43167 |
| 9. | 76598266 | [16] | LOCK WASHER | MAC Superseded by part number: 11194274 |
