纽荷兰零件查询(DC80) - CRAWLER DOZER (N.A. VERSION) (4/99-) (9.600[01B]) - CAB DC80 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
513 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76605374 | [1] | CAB | MAC Superseded by part number: 76606076 |
| 2. | 76598553 | [1] | RH CAB DOOR | MAC |
| 3. | 76598554 | [1] | LH CAB DOOR | MAC |
| 4. | 76598555 | [2] | CAB GLASS | MAC |
| 5. | 76598556 | [1] | GASKET | MAC |
| 7. | 76598557 | [1] | CAB GLASS | MAC |
| 9. | 76598558 | [2] | CAB GLASS | MAC |
| 11. | 76598559 | [1] | CAB GLASS | MAC |
| 13. | 76598563 | [1] | BOX | MAC |
| 14. | 76598564 | [4] | SCREW | MAC |
| 15. | 76590723 | [4] | LOCK WASHER | MAC Superseded by part number: 10517274 |
| 16. | 76590732 | [4] | WASHER | MAC |
| 17. | 76598561 | [39] | INSULATING WASHER | MAC |
| 18. | 76598562 | [78] | INSULATING WASHER | MAC |
| 19. | 76598566 | [39] | INSULATING WASHER | MAC |
| 20. | 76598567 | [39] | SCREW | MAC Superseded by part number: 12577521 |
| 21. | 76598568 | [2] | CAB GLASS | MAC |
| 22. | 76590929 | [39] | NUT | MAC Superseded by part number: 43362 |
| 23. | 76598569 | [39] | COVER | MAC |
| 24. | 76598570 | [1] | LH DOOR LOCK | MAC |
| 25. | 76598571 | [1] | LH DOOR LOCK | MAC |
| 26. | 76598572 | [4] | SCREW | MAC |
| 27. | 76598573 | [2] | SHIM | MAC |
| 28. | 76598574 | [2] | SHIM | MAC |
| 29. | 76598575 | [2] | HANDLE | MAC |
| 30. | 76590873 | [2] | WASHER | MAC Superseded by part number: 10519404 |
| 31. | 76593328 | [2] | SCREW | MAC Superseded by part number: 86977786 |
| 32. | 76598576 | [4] | SCREW | MAC |
| 33. | 76598577 | [4] | WASHER | MAC |
| 36. | 76591364 | [4] | SCREW | MAC Superseded by part number: 628-8020 |
| 37. | 76590847 | [4] | WASHER | MAC Superseded by part number: 10519624 |
| 38. | 76598578 | [2] | HANDLE | MAC Superseded by part number: 79096224 |
| 39. | 76598579 | [4] | SCREW | MAC |
| 40. | 76598580 | [2] | HOOK | MAC |
| 41. | 76598581 | [2] | HOOK | MAC |
| 43. | 76598582 | [1] | FOOT BOARD | MAC |
| 44. | 76605375 | [1] | INSULATING PANEL | MAC |
| 45. | 76591021 | [39] | LOCK WASHER | MAC |
| 46. | 76590895 | [39] | WASHER | MAC Superseded by part number: 86639313 |
| 48. | 76590848 | [6] | NUT | MAC Superseded by part number: 15503611 |
| 49. | 76591345 | [2] | STOP DEVICE | MAC |
| 50. | 76598511 | [3] | SCREW | MAC |
| 53. | 76590928 | [3] | SCREW | MAC Superseded by part number: 16043824 |
| 57. | 76590934 | [24] | NUT | MAC Superseded by part number: 12574221 |
| 58. | 76593313 | [6] | HINGE | MAC |
| 59. | 76591349 | [24] | SCREW | MAC Superseded by part number: 14441431 |
| 60. | 76593253 | [3] | LOCK | MAC |
| 60. | 75128717 | [3] | WRENCH | NHKEY, LOCK |
| 62. | 76591351 | [1] | COVER | MAC |
| 63. | 76591354 | [2] | COVER | MAC- 591x 344 mm |
| 63. | 76606034 | [2] | COVER | MAC- 671x384 mm - Also Needed on Machines Fitted with New Cab before the S/N Breaks |
| 64. | 76598586 | [2] | COVER PLATE | MAC |
| 65. | 76598587 | [2] | STOP DEVICE | MAC |
| 66. | 76598588 | [1] | STOP DEVICE | MAC |
| 69. | 76598589 | [1] | BLOCK | MAC |
| 70. | 76505376 | [1] | SHIELD | TOR Superseded by part number: 76605376 |
| 71. | 76605377 | [1] | SHIELD | MAC |
| 72. | 13550521 | [4] | WASHER,12.2mm ID x 24mm OD x 3mm Thk | MKT Superseded by part number: 17097324 |
| 73. | 10571970 | [4] | LOCK WASHER | LEC Superseded by part number: 10571971 |
| 74. | 76591134 | [4] | SCREW | MAC Superseded by part number: 11112124 |
| 75. | 76610337 | [1] | RUBBER SEAL | MAC |
