神钢零件查询(F4HFE6131 B003) - ENGINE 5801858658 IPU 280B TIER4 B (1/16-) (10.103.AK) - CRANKCASE COVERS, REAR GEAR, HOUSING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
312 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899026 | [2] | DOWEL,M18 x 10 | TOR |
| 1. | 4899126 | [2] | THREADED INSERT | SM Superseded by part number: 17873571 |
| 2. | 4899078 | [4] | SCREW,Hex Flg, M8 x 1.25 x 45 | TOR |
| 3. | 4899093 | [2] | BOLT,Hex Flange, M10 x 30.00mm, Cl 10.9, PHC | BAS Superseded by part number: 87778358 |
| 3. | 4899073 | [1] | SCREW,Hex Flg, M12 x 1.75 x 30 | TOR |
| 4. | 4896939 | [3] | SCREW,M10 x 1.5 x 50mm | TORM10 x 1,5 x 50 |
| 5. | 2859269 | [1] | HOUSING | TOR Superseded by part number: |
