| 1. |
214817
|
[6] |
SPACER
|
CAS
|
| 2. |
703736
|
[6] |
BOLT,Hex, 1/2" - 13 x 2 3/4", Gr 5
|
CAS
SCREW hex cap, 1/2-13 x 2-3/4
|
| 3. |
705541
|
[6] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2
|
| 4. |
700150032
|
[1] |
BEARING ASSY,50.8 mm ID x 100 mm OD x 7 mm
|
HFI
ASM (Includes: Ref. 5)
|
| 5. |
712158
|
[3] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
spherical Superseded by part number: 47577203
|
| 6. |
700150015
|
[1] |
ROLLER
|
HFI
ASSEMBLY Superseded by part number: 700162182
|
| 7. |
433-824
|
[14] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
Superseded by part number: 280420, 72187237
|
| 8. |
231-5348
|
[14] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
hex flange top lock, 1/2-13 GR/G Superseded by part number: 86521610
|
| 9. |
700150018
|
[2] |
RING
|
HFI
WA-grass, lower
|
| 10. |
700135117
|
[2] |
RING
|
HFI
grass
|
| 11. |
700719705
|
[1] |
ROLLER
|
HFI
rubber
|
| 12. |
700132763
|
[1] |
BEARING ASSY
|
HFI
ASM Superseded by part number: 700150032
|
| 13. |
700135023
|
[2] |
HOUSING
|
HFI
ASM (Includes: Ref. 5)
|
| 14. |
409-7612
|
[7] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 15. |
232-5316
|
[10] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 16. |
121-237
|
[3] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
hex flange, 3/8-16 x 1-1/4 GR. 8 Superseded by part number: 87327172
|
| 17. |
700132957
|
[2] |
PLATE
|
HFI
|
| 18. |
700109753
|
[1] |
BEARING ASSY,97 mm ID x 108 mm OD x 33 mm
|
CAS
ASM (Includes: Ref. 5)
|
| 19. |
413-1232
|
[6] |
BOLT,Hex, 3/4" - 10 x 2", Gr 5
|
CAS
Superseded by part number: 88557
|
| 20. |
492-11075
|
[6] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 21. |
705566
|
[4] |
WASHER
|
IH
hardened plain, 3/4
|
| 22. |
8050825
|
[3] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
cylindrical Superseded by part number: F82059
|
| 23. |
700132835
|
[1] |
ROLLER
|
HFI
ASM (Includes: Ref. 22, 25 & 26)
|
| 24. |
700124612
|
[2] |
ROLLER
|
CAS
ASM (Includes: Ref. 22)
|
| 25. |
700132833
|
[1] |
SHAFT
|
HFI
|
| 26. |
F82059
|
[2] |
BEARING ASSY,38.1mm ID x 80mm OD x 22mm W
|
IH
cylindrical
|
| 27. |
700132834
|
[1] |
SUPPORT
|
HFI
roller
|
| 28. |
700100927
|
[2] |
HUB
|
L
|
| 29. |
700132962
|
[1] |
BEARING ASSY,55.56 mm ID x 100 mm OD x 33 mm
|
HFI
ASM (Includes: Ref. 30) Superseded by part number: 76451
|
| 30. |
700704263
|
[1] |
SPHERICAL BEARING,55.562 mm ID x 100 mm OD x 48.4 mm
|
CAS
spherical Superseded by part number: 76451
|
