神钢零件查询(F4HFE6131 B003) - ENGINE 5801858658 IPU 280B TIER4 B (1/16-) (10.106.AO) - ROCKER ARM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
437 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899257 | [1] | HOUSING | TORASSY |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONHousing, Incl in 1 |
| 3. | 2859464 | [2] | RETAINER,10.79mm ID, 7.63mm ID | TOR Superseded by part number: |
| 5. | 2859460 | [1] | ROCKER ARM | TORASSY, Incl 3, 4, 6 |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONASSY, Incl 7 - 10 |
| 7. | 2859467 | [2] | NUT,Hex, 3/8" - 24, RH | TOR Superseded by part number: |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONRocker, Incl in 6 |
| 9. | 2859468 | [2] | ADJUSTMENT SCREW,3/8" - 24 x 23.85mm | TOR Superseded by part number: |
| 10. | 2859470 | [2] | SOCKET | TOR |
| 11. | NS | [1] | NOT SERVICED | BASRocker Arm, Incl 5, 13, 19, 20, 23 |
| 12. | 2852428 | [6] | WIRE CLAMP,6mm ID | TOR Superseded by part number: 504066132 |
| 13. | 2859462 | [1] | ROCKER ARM | TORASSY, Incl 3, 4, 14 |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONASSY, Incl 7, 9, 10, 16 |
| 15. | 4899245 | [5] | SLEEVE,9mm ID x 13.9mm OD x 55.25mm L | TOR |
| 16. | NSS | [1] | NOT SOLD SEPARAT | CONRocker, Incl in 14 |
| 17. | 4895432 | [5] | SCREW,M8 x 1.25 x 70mm | TORM8 x 1,25 x 70 |
| 18. | 4899089 | [2] | SCREW,Hex Flg, M8 x 1.25 x 50 | TOR |
| 19. | 2856460 | [2] | BOLT,Flng, M8 x 1.25 x 55.5mm, Cl 10.9 | TOR |
| 20. | 2859463 | [1] | SUPPORT | TOR Superseded by part number: |
| 21. | 4895031 | [12] | PUSH ROD | TOR |
| 23. | NS | [1] | NOT SERVICED | BASBushing |
