| 1. | 328712A2 | [1] | FLEXIBLE DRIVE SHAFT | BURDriveshaft; Component Parts Not Serviced Separately; Order 87400942 Kit For Service |
| . . | 87400942 | [1] | UNIVERSAL JOINT | BURDriveshaft U-Joint; Incl. (4) 87280463 Snap rings, Plus A Cross Bearing Kit Which Is Not Serviced Separately that Includes (1) Spider, (4) Bearings, (4) Snap rings, (4) Lock Plates, (8) Bolts Superseded by part number: 84355344 |
| 2. | 627-16045 | [4] | BOLT,Hex, M16 x 2 x 45mm, Cl 10.9, Full Thd | CASUse with Loctite 243 Superseded by part number: 86508624 |
| 3. | 896-11016 | [4] | WASHER,17.5mm ID x 30mm OD x 4mm Thk | IH Superseded by part number: 86625266 |
| 4. | 385750A1 | [2] | COVER | BURFlywheel Housing |
| 5. | 614-10025 | [6] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8 | CAS Superseded by part number: 11106231 |
| 6. | 140028 | [6] | WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | NH |
| 7. | 401630A2 | [1] | HYDROSTATIC PUMP | BURTandem; See Figure 06-13 Superseded by part number: 84417898 |
| 7. | 401630A2R | [1] | REMAN-HYD PUMP | BURDC85 Crawler Dozer, Tandem (8/04-), Reman for New PN 401630A2 |
| 7. | 401630A2C | [1] | CORE-HYDRAULIC PUMP | BURReturn Part Number |
| 8. | 447840A1 | [1] | BRACKET, SUPPORTING | BURFront Pump Support |
| 9. | 430920A1 | [1] | BRACKET, SUPPORTING | BURRear Pump Support |
| 10. | 814-12080 | [4] | BOLT,Hex, M12 x 1.75 x 80mm, Cl 8.8 | CASM12 x 80 Superseded by part number: 43158 |
| 11. | 896-15012 | [4] | WASHER,13.5mm ID x 28mm OD x 4mm Thk | CAS13,5 x 28 x 4 mm Superseded by part number: 86625256 |
| 12. | A59514 | [4] | RUBBER BUSHING,13.49mm ID x 34.29mm OD x 41.1mm L | CASFront Mount |
| 13. | D25022 | [4] | WASHER | CAS |
| 14. | 832-10412 | [4] | NUT,M12 x 1.75, Cl 8 | CAS Superseded by part number: 87780366, 412126 |
| 15. | 814-12050 | [4] | BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8 | CAS Superseded by part number: 9706702 |
| 18. | 627-12025 | [2] | BOLT,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd | CASUse with Loctite 243 Superseded by part number: 398792 |
| 20. | L33673 | [1] | OIL SEAL | CASOil Seal Superseded by part number: 73048835 |
