神钢零件查询(F4HFE6132 A003) - ENGINE 5801753676 - 47541755 (1/14-) (10.101.AA) - CYLINDER HEAD Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
174 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831279 | [1] | CYLINDER HEAD,6 Cylinders | TORASSY, Incl 2 - 8 |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONCylinedr head, Incl in 1 |
| 3. | 4895085 | [13] | EXPANSION PLUG,25.74mm | TOR |
| 4. | 4895406 | [7] | EXPANSION PLUG,9.8mm OD | TOR |
| 5. | 4895089 | [11] | PLUG,0.886" L | TOR |
| 6. | 4895407 | [2] | EXPANSION PLUG,38.28mm OD | TOR |
| 7. | 4897578 | [12] | VALVE SEAT,28mm ID x 34.9mm OD x 5.75mm L | TORRight |
| 7. | 4897106 | [12] | VALVE SEAT,28mm ID x 34.9mm OD x 5.75mm L | TORLeft |
| 8. | 4893036 | [1] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 10. | 4891024 | [12] | BOLT,Flng, M12 x 1.75 x 130mm | TOR |
| 10. | 4891025 | [14] | SCREW,Flng, M12 x 1.75 x 150mm | TOR |
