纽荷兰零件查询(DC85) - CRAWLER DOZER (8/04-) (04-19) - INSTRUMENT CLUSTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
552 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87434892 | [1] | CLUSTER, INSTR. | BURInstrument Cluster; Incl. Ref 1 - 6 |
| 1. | 370755A1 | [1] | BEZEL | CASBlack Trim |
| . . | NSS | [2] | NOT SERVICED SEPARATELY | CONScrew, No. 6 x 1/4; Trim |
| 2. | 370756A1 | [1] | LENS | CASClear; Includes O-Ring, Which Is Not Serviced Separately |
| 5. | 370760A1 | [1] | REAR COVER | CASIncludes O-Ring, Which Is Not Serviced Separately |
| 6. | 388053A2 | [1] | BULB,14V, 1W | CAS1W x 14V; Includes Socket |
