纽荷兰零件查询(DC85) - CRAWLER DOZER (8/04-) (04-23) - GRID HEATER - CABLES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
632 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87410603 | [1] | PLATE | IMOCold Start; See Figure 04-23 For Fuses and Relays |
| 2. | 87410265 | [1] | BAR | IMO90 mm Jumper Copper Plate; Fuse To Relay |
| 3. | 87410602 | [1] | FUSE,300 Amp | IMO300 Amp |
| 4. | 322357 | [2] | BELLEVILLE WASHER,M6 x 14mm OD x 1.3mm Thk | NH |
| 5. | 829-1406 | [4] | NUT,Hex, M6 x 1, Cl 10.9 | CAS Superseded by part number: 86500688, 87778396 |
| 6. | 87442552 | [1] | CABLE ASSY. | BUR575 mm Wire; Relay To Grid Heater |
| 7. | 87433544 | [1] | WIRE HARNESS | BURController Harness, Cold Start Control; Attaches To Engine Harness |
| 8. | 87419615 | [1] | CABLE ASSY. | BUR1250 mm Wire; Starter To Fuse Block |
| 9. | 895-11006 | [2] | WASHER,M6 x 12mm OD x 1.6mm | CAS Superseded by part number: 86588450 |
| 10. | 87413162 | [1] | GROUND STRAP | IMO150 mm Ground Wire |
| 11. | 82017872 | [1] | HEATER | ZEDGrid |
| 12. | 440038A1 | [1] | JUNCTION BLOCK | RACFuse Block, Includes Hardware Superseded by part number: 87302554 |
| 13. | 242999A1 | [1] | CLAMP | CASDouble (Replaces the Non Cold Start Clamp) |
| 14. | 515-23190 | [1] | CLAMP,3/4", Insul, 3/8" Bolt | CAS Superseded by part number: 86624005 |
