| 1. |
218-5057
|
[1] |
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
|
CAS
Incl. Ref. 45 Superseded by part number: 76350
|
| 2. |
700719099
|
[1] |
HYDRAULIC HOSE,0.38" ID x 21.26", SAE J516, SAE J343
|
HFI
hydraulic
|
| 3. |
700718765
|
[1] |
FITTING
|
HFI
CONNECTOR straight, includes: REF. 49
|
| 4. |
218-840
|
[2] |
TEE,37 Degree, 3/4"-16 x 3/4"-16, Fem Sw Br
|
CAS
Superseded by part number: 86513015
|
| 5. |
218-5070
|
[1] |
HYD CONNECTOR,3/4" - 16 Male JIC x 1-1/16" - 12 Male ORB
|
CAS
straight, includes: REF. 48 Superseded by part number: 87329794
|
| 6. |
700719469
|
[1] |
PUMP
|
HFI
ASSY. piston Superseded by part number: 700132588
|
| 7. |
700710984
|
[2] |
SCREW,Hex Flg, 1/2" x 1 1/4", G8 NC
|
CAS
|
| 8. |
231-5348
|
[2] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2"-13, hex. flange top lock, GR/G Superseded by part number: 86521610
|
| 9. |
700719471
|
[1] |
VALVE, CONTROL
|
HFI
ASSY. baler tension Superseded by part number: 700726578
|
| 10. |
218-5106
|
[1] |
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
|
CAS
Includes Ref. 46 Superseded by part number: 72186176, 128830
|
| 11. |
700719111
|
[1] |
HOSE
|
HFI
hydraulic
|
| 12. |
8027427
|
[1] |
GROMMET
|
CAS
|
| 13. |
700719102
|
[1] |
HYDRAULIC HOSE,0.63" ID x 50.20", SAE 100R1, SAE J517, SAE J516, SAE J343
|
HFI
hydraulic
|
| 14. |
218-5137
|
[1] |
ELBOW,45 Degree Elbow, 7/8" - 14 Male JIC x 7/8" - 14 Male ORB
|
CAS
Incl. Ref 47 Superseded by part number: 72186185, 330345
|
| 15. |
409-7612
|
[8] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 16. |
700132716
|
[1] |
SUPPORT
|
HFI
valve
|
| 17. |
121-226
|
[6] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 18. |
232-5316
|
[12] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8"-16, hex. flange top lock, GR/G Superseded by part number: 86521609
|
| 19. |
413-672
|
[2] |
BOLT,Hex, 3/8" - 16 x 4-1/2", Gr 5
|
CAS
3/8"-16 x 4-1/2", hex. cap screw Superseded by part number: 86505980
|
| 20. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8", hardened, plain Superseded by part number: 86632588
|
| 21. |
218-5351
|
[1] |
HYD CONNECTOR,3/4"-16, 37 Degree x 9/16"-18, O-Ring
|
CAS
straight, includes: REF. 45 Superseded by part number: 86509028
|
| 22. |
218-5280
|
[1] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 9/16"-18, O-Ring
|
CAS
ELBOW 90°, includes: REF. 45 Superseded by part number: 86512938
|
| 23. |
700719472
|
[1] |
VALVE, CONTROL
|
HFI
ASSY. twine/pu/clutch
|
| 24. |
700719126
|
[1] |
HYDRAULIC HOSE,0.63" ID x 21.65", SAE100R1, SAE J517
|
HFI
hydraulic
|
| 25. |
700132747
|
[2] |
SUPPORT
|
HFI
WA, tank
|
| 26. |
218-1056
|
[1] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, NPTF
|
CAS
90° Superseded by part number: 216744
|
| 27. |
214-1420
|
[1] |
HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm
|
CAS
Superseded by part number: 507586
|
| 28. |
700714587
|
[1] |
SWITCH
|
CAS
temp.
|
| 29. |
217-433
|
[1] |
PLUG,Hex Soc, 1/4" - 18 NPTF
|
CAS
Superseded by part number: 9617020
|
| 30. |
700717883
|
[1] |
CAP
|
HFI
BREATHER
|
| 31. |
700719473
|
[1] |
RESERVOIR ASSY.
|
HFI
oil, includes: REF. 37 Superseded by part number: 700726577
|
| 32. |
700132750
|
[2] |
STRAP
|
HFI
|
| 33. |
221-215
|
[1] |
PIPE,Nipple, 3/4" NPT x 2"
|
CAS
2
|
| 34. |
700719488
|
[1] |
SWITCH
|
HFI
SENSOR low level
|
| 35. |
221-211
|
[1] |
PIPE,Nipple, 3/4" NPT x 1 3/8"
|
CAS
NIPPLE 1-3/8"
|
| 36. |
700726024
|
[1] |
TEE
|
HFI
swivel
|
| 37. |
700719687
|
[1] |
CAP
|
HFI
DIPSTICK
|
| 38. |
HFI746321
|
[1] |
ELBOW
|
HFI
90°, national pipe taper thread
|
| 39. |
742643
|
[1] |
FILTER
|
CAS
ASSY. includes: REF. 42
|
| 40. |
700719622
|
[1] |
FITTING
|
HFI
CONNECTOR straight
|
| 41. |
700719128
|
[1] |
HYDRAULIC HOSE,1.25" ID x 36.22", SAE 100R4, SAE J517
|
HFI
hydraulic Superseded by part number: 700728111
|
| 42. |
201021C1
|
[1] |
ELEMENT
|
IH
filter
|
| 43. |
700719125
|
[1] |
HOSE
|
HFI
hydraulic
|
| 44. |
306132C1
|
[2] |
CABLE TIE,14.5" L
|
IH
CABLE STRAP TIE Superseded by part number: 435437A1
|
| 45. |
738468
|
[1] |
O-RING
|
IH
3/8"
|
| 46. |
237-6008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
3/4" Superseded by part number: 128825
|
| 47. |
237-6010
|
[1] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
CAS
7/8" Superseded by part number: 72186125, 167269
|
| 48. |
738484
|
[1] |
O-RING
|
IH
1" Superseded by part number: 167266
|
| 49. |
237-6020
|
[1] |
O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro
|
CAS
Superseded by part number: 87779389, 570186
|
