凯斯零件查询(RS561A) - CASE IH ROUND BALER (1/99-12/00) (8-022) - PUMP ASSEMBLY, 700719469 COMPLETE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
996 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700719469
|
[1] |
PUMP
|
HFI
ASSY. complete Superseded by part number: 700132588
|
| 1. |
61-32520
|
[4] |
HEX SOC SCREW,1/4"-20 x 1 1/4"
|
CAS
SPL Superseded by part number: 81963
|
| 2. |
50-3601T1
|
[1] |
COVER
|
L
Superseded by part number: 86000724
|
| 3. |
700719775
|
[1] |
KIT
|
HFI
compensator
|
| 4. |
413-620
|
[4] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187207, 88011
|
| 5. |
700719772
|
[1] |
PLATE
|
HFI
back
|
| 6. |
700719776
|
[1] |
KIT
|
HFI
ASSY. rotating
|
| 7. |
700719778
|
[1] |
PISTON
|
HFI
|
| 8. |
95-81147
|
[1] |
WASHER,1.53" ID x 2.06" OD x 0.11" Thk
|
CAS
|
| 9. |
T36441
|
[1] |
THRUST BEARING,1.127" ID x 1.74" OD x 0.0781"
|
CAS
thrust Superseded by part number: 272201
|
| 10. |
A52205
|
[2] |
RACE,28.63mm ID x 44.2mm OD x 2.41mm Thk
|
CAS
BEARING race, thrust
|
| 11. |
700719770
|
[1] |
SHAFT
|
HFI
drive
|
| 12. |
7037195
|
[1] |
NEEDLE BEARING
|
CAS
|
| 13. |
700719774
|
[1] |
HOUSING
|
HFI
|
| 14. |
700718773
|
[2] |
PIN, ROLL
|
HFI
|
| 15. |
50-2798T1
|
[1] |
SPRING
|
L
Superseded by part number: 86512855
|
| 16. |
50-2799T1
|
[1] |
COLLAR
|
L
spring Superseded by part number: 86512851
|
| 17. |
50-1793T1
|
[1] |
BUTTON
|
L
pivot Superseded by part number: 86512850
|
| 18. |
38-11208
|
[1] |
LOCK PIN,3/16" x 1/2", Slotted
|
CAS
Superseded by part number: 88626
|
| 19. |
700719777
|
[1] |
PLATE
|
HFI
cam
|
| 20. |
7038128
|
[2] |
BEARING, NEEDLE
|
HFI
thrust Superseded by part number: A14858
|
| 21. |
D66352
|
[2] |
BUSHING
|
CAS
RACE inner Superseded by part number: 86512847
|
| 22. |
D66359
|
[2] |
COVER
|
CAS
trunnion Superseded by part number: 272194
|
| 23. |
700719706
|
[1] |
SEAL KIT
|
HFI
KIT
|
