凯斯零件查询(RS561A) - CASE IH ROUND BALER (1/99-12/00) (7-016) - LATCH SUPPORT ASSEMBLIES, LEFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
822 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700135610
|
[1] |
SHIELD
|
HFI
lower, L.H.
|
| 2. |
700150182
|
[2] |
SPACER
|
HFI
|
| 3. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8"-16 x 1-1/4", hex. flange , GR8 Superseded by part number: 87327172
|
| 4. |
232-5316
|
[10] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8"-16, hex. flange top lock, GR/G Superseded by part number: 86521609
|
| 5. |
409-7612
|
[5] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 6. |
700132794
|
[1] |
OPEN END WRENCH
|
HFI
|
| 7. |
863415
|
[1] |
PIN
|
CAS
klik
|
| 8. |
121-226
|
[3] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 9. |
700153715
|
[1] |
SHIELD
|
HFI
upper L.H., includes: Decals
|
| 10. |
700715104
|
[4] |
BUMPER
|
CAS
|
