沃尔沃零件查询D9A2A; D9A2A D9-425; D9A2A D9-500; D9A2A D9-500 (R4); D9A2A D9-575; D9A2B D9-425; D9A2B D9-500 (R5); D9A2B D9-575; D9A2C D9-425; D9A2D D9EngineFlywheel housing SN-7009169424EPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
912 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3587606
|
[1] |
Flywheel housing
|
|
| 2. |
994264
|
[1] |
Flange screw
|
|
| 3. |
3839406
|
[1] |
Cap
|
|
| 4. |
8148259
|
[1] |
Crankshaft seal
|
SN-7009195515
|
| 4. |
22086413
|
[1] |
Crankshaft seal
|
SN7009195516-
|
| 5. |
969189
|
[5] |
Flange screw
|
L=85mm
|
| 6. |
966367
|
[6] |
Flange screw
|
L=100mm
|
| 6. |
966369
|
[1] |
Flange screw
|
L=120mm
|
| 7. |
965197
|
[4] |
Flange screw
|
L=100mm
|
| 8. |
984734
|
[4] |
Flange screw
|
L=20mm
|
| 8. |
975199
|
[2] |
Flange screw
|
L=35mm
|
| 8. |
975192
|
[1] |
Flange screw
|
L=100mm
|
| 9. |
20728511
|
[1] |
Timing gear cover
|
(20451300)
|
| 10. |
|
|
|
|
| 11. |
|
|
|
|
| 12. |
20564008
|
[1] |
Sealing strip
|
(20547565)
|
| 13. |
20572441
|
[2] |
Gasket
|
|
| 14. |
1161231
|
[1] |
Sealant
|
304ml
|
| 14. |
1161277
|
[1] |
Sealant
|
20g
|
| 15. |
3589187
|
[1] |
Lifting eye
|
P
|
| 16. |
990809
|
[8] |
Flange screw
|
|
| 17. |
3586761
|
[1] |
Lifting eye
|
S.B
|
