凯斯零件查询(RS561A) - CASE IH ROUND BALER (1/99-12/00) (7-038) - MESH WRAP ROLLER SUPPORT ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
127 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700148764
|
[1] |
ROD
|
HFI
|
| 2. |
700148602
|
[1] |
PIVOT
|
HFI
WA, L.H.
|
| 3. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 4. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8"-16, hex. flange top lock, GR/G Superseded by part number: 86521609
|
| 5. |
700148758
|
[1] |
PANEL
|
HFI
|
| 6. |
433-612
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 7. |
496-81010
|
[6] |
WASHER
|
CAS
3/8", hardened, wide, plain Superseded by part number: 86625244
|
| 8. |
360-816
|
[4] |
BOLT,Hex, 1/2" - 13 x 1", Gr 8
|
CAS
1/2"-13 x 1", hex. flange, GR8 Superseded by part number: 87034823
|
| 9. |
231-5348
|
[6] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2"-13, hex. flange top lock, GR/G Superseded by part number: 86521610
|
| 10. |
700148603
|
[1] |
PIVOT
|
HFI
WA, R.H.
|
| 11. |
700148760
|
[2] |
SUPPORT
|
HFI
WA
|
| 12. |
T54573
|
[1] |
PIN
|
IH
.120 wire hair, cotter Superseded by part number: 87421748
|
| 13. |
700710049
|
[1] |
WASHER
|
CAS
3/8", fender
|
| 14. |
700148762
|
[1] |
ARM
|
HFI
WA
|
| 15. |
413-888
|
[2] |
BOLT,Hex, 1/2" - 13 x 5-1/2", Gr 5
|
CAS
1/2"-13 x 5-1/2", hex. cap screw Superseded by part number: 88576
|
| 16. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2", hardened, plain
|
| 17. |
700148784
|
[1] |
SHAFT
|
HFI
PIPE
|
| 18. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
