| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 86984309 | [1] | SCREEN | BURRear Screen |
| 2. | 86984307 | [1] | SUPPORT | BUR |
| 3. | 814-8090 | [2] | BOLT,Hex, M8 x 1.25 x 90mm, Cl 8.8 | CASM8 x 90 Superseded by part number: 86508571 |
| 4. | 895-15008 | [4] | WASHER,M8 x 20 x 1.6 | CAS Superseded by part number: 86625263 |
| 5. | 832-10408 | [2] | NUT,M8 x 1.25, Cl 8 | CAS Superseded by part number: 86528579 |
| 6. | 614-10025 | [4] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8 | CAS Superseded by part number: 11106231 |
| 7. | 895-15010 | [4] | WASHER,M11 x 24 x 2 | CAS Superseded by part number: 86625253 |
| 8. | 122958A1 | [4] | SQUARE NUT | CASSquare, M10 Superseded by part number: 230427A1 |
| 9. | 336371A1 | [4] | PIN | CASNut Retainer |
| 10. | 86984314 | [1] | SUPPORT | BURHold Open |
| 11. | 614-10030 | [2] | BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd | IH Superseded by part number: 43140 |
| 13. | 832-10410 | [1] | NUT,M10 x 1.5, Cl 8 | CAS Superseded by part number: 190003888452 |
| 14. | 814-10090 | [2] | BOLT,Hex, M10 x 1.5 x 90mm, Cl 8.8 | CAS |
| 15. | 896-15010 | [2] | WASHER,11mm ID x 24mm OD x 3mm Thk | CAS11 x 24 x 3 mm Superseded by part number: 86639325 |
