纽荷兰零件查询(DC85) - CRAWLER DOZER (8/04-) (09-48) - DECALS - ENGLISH New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
731 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 332512A1 | [2] | DECAL | CASWarning; Entanglement Hazard |
| 3. | 383973A1 | [2] | DECAL | CASDanger; Jump Start, Battery |
| 4. | 329044A1 | [1] | WARNING DECAL | CASRadiator Cap |
| 5. | 321-7030 | [1] | WARNING DECAL | CASDo Not Jump |
| 6. | 382622A1 | [1] | DECAL | CASWarning; Read the Operator's Manual |
| 8. | 321-7040 | [1] | DANGER DECAL | CASEngine Start Warning Superseded by part number: 84135011 |
| 9. | 87420954 | [1] | DECAL | BURDozer Blade Control Pattern |
| 10. | 87451954 | [1] | LARGE PLATE | CASPLATE, LARGE Decal Mounting, Used With Ref 3, 8, 11, 12 |
| 11. | 614-10025 | [2] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8 | CASReplaces M12 x 25 614-12025 Bolt Used On Some Models Superseded by part number: 11106231 |
| 12. | 140028 | [2] | WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | NHReplaces M12 892-11012 lock washer used on some models |
| 13. | 87412050 | [1] | DECAL | BURImportant; Track Tension |
| 20. | 87422190 | [1] | DECAL | BURRipper Control Pattern |
| 21. | 76067229 | [1] | DECAL | LECAt 12 Volt Plug Receptacle; Cab Models |
| 22. | 87416964 | [1] | DECAL | BURLift And Tie Down Warning |
| 23. | 87416965 | [1] | DECAL | BURLift And Tie Down Instructions |
| 24. | 8603092 | [1] | WARNING DECAL | FARWarning, Explosion Hazard, Do Not Use Ether |
