神钢零件查询(F4HFE6133 B003) - ENGINE 5801843802 - 47637346 TIER4 B (1/13-) (55.010.AA) - ENGINE, CABLE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
528 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 2852500 | [2] | CLAMP | TOR Superseded by part number: |
| 3. | 2852484 | [3] | FLANGE NUT,Hex, M6 x 1 | TOR Superseded by part number: 17044625 |
| 3. | 2852389 | [2] | FLANGE NUT | TOR Superseded by part number: 17044725 |
| 4. | 47401109 | [3] | WIRE HARNESS | BRR |
| 5. | 2852776 | [3] | WASHER,6mm ID x 11mm OD | TOR Superseded by part number: 17094614 |
| 6. | 2852602 | [3] | HEX SOC SCREW,M6 x 16mm | SM Superseded by part number: 16689121 |
