纽荷兰零件查询(DC85) - CRAWLER DOZER (8/04-) (05-09) - TRACK CHAIN, SEALED New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
502 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87365698 | [2] | CHAIN (CE) | BUR457 mm (18 inch); Chain; Incl. Shoes; Incl. 407014A1, Ref 1 - 8; 9, 10, 11 |
| . . | 87404012 | [2] | CRAWLER TRACK ASSY | BUR508 mm (20 inch); Chain; Incl. Shoes; Incl. 407014A1, Ref 1 - 8; 9A, 10, 11 |
| . . | 86982102 | [2] | CRAWLER TRACK ASSY | BUR610 mm (24 inch); Chain; Incl. Shoes; Incl. 407014A1, Ref 1 - 8; 9B, 10, 11 |
| . . | 86982104 | [2] | CRAWLER TRACK ASSY | BUR711 mm (28 inch); Chain; Incl. Shoes; Incl. 407014A1, Ref 1 - 8; 9C, 10, 11 |
| . . | 86982093 | [1] | TRACK CHAIN | BHBIncl. Ref 1 - 8 Superseded by part number: 407014A1 |
| 1. | 295178A2 | [39] | LINK | BURRight-Hand |
| 2. | 295177A2 | [39] | LINK | BURLeft-Hand |
| 3. | R56517 | [38] | BUSHING | CAS123,5 mm (4-7/8 in) OD; Link |
| 4. | R50211 | [156] | WASHER | CAS |
| 5. | R49792 | [38] | PIN,33.48mm OD x 183.5mm L | CAS183 x 33 mm |
| 6. | R54349 | [1] | PIN,33.04mm OD x 183.5mm L | BURMaster Link |
| 7. | R56516 | [1] | BUSHING,33.8mm ID x 56.9mm OD x 107.6mm L | CAS108 mm (4-1/4 in) OD; Master Link |
| 8. | R50210 | [2] | SPACER | CAS |
| 9. | 295181A1 | [39] | TRACK SHOE | CAS457 mm (18 inch) |
| 9A. | 300199A1 | [39] | SHOE | CAS508 mm (20 inch) |
| 9B. | 295182A1 | [39] | SHOE | CAS610 mm (24 inch) |
| 9C. | 295183A1 | [39] | SHOE | CAS711 mm (28 inch) |
| 10. | 295318A1 | [156] | BOLT,Hex, 5/8" - 18 x 2 1/8" | CAS5/8 NF x 2-1/8 |
| 11. | K134536 | [156] | NUT | CAS5/8 NF Superseded by part number: PK134536 |
| . . | 86982396 | [1] | KIT | BHBIncl. Ref 12 - 18; Incl. Instructions |
| . . | 434144A1 | [1] | SERVICE KIT | BURPin and Bushing Kit; Incl. Ref 19 - 24 Superseded by part number: R50210, R56517, R49792, R50211, R56516, R54281 |
| 23. | R54281 | [2] | PIN,33.41mm OD x 183.5mm L | CASMaster Link |
