神钢零件查询(F4HFE6136 B003) - ENGINE 5801939277 47603479 SPRAYER PATRIOT 2250 T4B (7/15-) (10.101.AB[01]) - CYLINDER HEAD, COVER, UP TO SERIAL NUMBER 1462087 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
640 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 504262827 | [1] | CAP | TORASSY, Incl 3, 4 |
| 3. | 98412146 | [1] | GASKET | TOR Superseded by part number: 2852774 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 2 |
| 5. | 504075125 | [6] | FLANGE NUT | TOR Superseded by part number: 4893936 |
| 6. | 504070038 | [1] | GASKET | SM Superseded by part number: 2853784 |
| 7. | 504070041 | [6] | GASKET | TOR Superseded by part number: 4899239 |
| 8. | 504371134 | [1] | VALVE | TOR Superseded by part number: |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONCover, Incl in 1 |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONTube, Incl in 10 |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONO-ring, Incl in 10 |
| 13. | 504129243 | [2] | SCREW | SCREW |
| 14. | 504088235 | [4] | SCREW | CUR |
| 15. | 42568767 | [1] | FILTER | BN |
| 17. | 16597225 | [3] | BOLT,M6 x 18mm | TOR Superseded by part number: 2853118 |
