HK40634
|
[1] |
8511 BALE THROWER KIT COMPLETE
|
|
| 1. |
700112662
|
[2] |
ROD
|
CAS
WA
|
| 2. |
6143358
|
[9] |
BUSHING
|
HFI
SPACER Superseded by part number: 50061K
|
| 3. |
NLS
|
[10] |
NO LONGER SERVICED
|
BAS
5/8 HARDENED PLAIN WASHER
|
| 4. |
700703922
|
[4] |
LOCK NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 5. |
703249
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| 6. |
705533
|
[2] |
WASHER
|
NNA
3/8 HARDENED PLAIN WASHER Superseded by part number: 496-11041, 496-11041, 80702
|
| 7. |
705038
|
[2] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 8. |
704023
|
[2] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 9. |
1662543
|
[2] |
CHAIN (AG)
|
CAS
CHAIN - welded (18 links)
|
| 10. |
62349
|
[2] |
LOCK WASHER
|
NNA
.148 X 2-3/4 HAIR PIN COTTER Superseded by part number: 87790435, 87790435, 9966809, 87790435, 9966809, S120261
|
| 11. |
1662519
|
[2] |
SHIELD
|
CAS
- bale chute
|
| 12. |
1662535
|
[2] |
PIN
|
CAS
- hinge
|
| 13. |
1662527
|
[1] |
ROD
|
CAS
PIN - chute
|
| 14. |
700112688
|
[1] |
CHUTE (DOWNWARD)
|
CAS
CHUTE - upper
|
| 15. |
700106235
|
[1] |
PIN
|
CAS
- hinge
|
| 16. |
700115574
|
[1] |
CHUTE ASSY.
|
CAS
CHUTE - lower
|
| 17. |
700047
|
[10] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 18. |
231-4116
|
[2] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 19. |
703793
|
[1] |
BOLT,Hex, 5/8" - 11 x 1 3/4", Gr 5, Full Thd
|
CAS
5/8-11 X 1-3/4 C Superseded by part number: 9627896
|
| 20. |
700112651
|
[1] |
FRAME
|
CAS
- mounting
|
| 21. |
700106060
|
[1] |
SPACER
|
CAS
BUSHING - lower
|
| 22. |
701771
|
[1] |
SUPPORT
|
NNA
5/8-11 X 2-1/4 C Superseded by part number: 413-1036
|
| 23. |
704247
|
[8] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| 24. |
705574
|
[1] |
WASHER,1 1/8" x 2" x .156", HDN
|
CAS
|
| 25. |
700112673
|
[1] |
FRAME
|
CAS
- chute (Includes item 41)
|
| 26. |
703959
|
[2] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd
|
CAS
1/2-13 X 1 C
|
| 27. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 28. |
86516876
|
[6] |
1/2-13 H
|
COVER
|
| 29. |
7827116
|
[2] |
ROLLER
|
CAS
PAD - rubber
|
| 30. |
700111507
|
[2] |
CLEVIS
|
CAS
- clip
|
| 31. |
7758253
|
[2] |
SPRING
|
CAS
- compression
|
| 32. |
704130
|
[4] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
| 33. |
700013
|
[6] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 X 3/4 RHSNB
|
| 34. |
704239
|
[6] |
FRONT AXLE
|
NNA
5/16-18 HFSLN Superseded by part number: 231-5145, 231-5145, NLS
|
| 35. |
378604
|
[4] |
SPACER
|
CAS
BUSHING
|
| 36. |
701235
|
[4] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 C
|
| 37. |
700709605
|
[4] |
WASHER,1/2"
|
CAS
1/2 WIDE PLAIN WASHER Superseded by part number: 80700
|
| 38. |
700115573
|
[1] |
SHIELD
|
CAS
- lower
|
| 39. |
700112051
|
[2] |
TUBE
|
CAS
PIPE - cross
|
| 40. |
700112341
|
[2] |
STRAP
|
CAS
- link
|
| 41. |
41277
|
[1] |
SOCKET
|
CAS
BRACKET Superseded by part number: A59457, A59457, NLS
|
| 42. |
78311
|
[1] |
DECAL
|
CAS
- caution Superseded by part number: 700714229
|
| 43. |
700708161
|
[1] |
DECAL
|
CAS
8511 Superseded by part number: 1976038C1
|
