凯斯零件查询(8520) - CASE IH RECTANGULAR BALER (1/88-12/99) (9-56) - HYDRAULIC PUMP AND CLUTCH ASSEMBLY (GEAR PUMP) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
796 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
702035
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 X 12-1/4 C
|
| 2. |
705038
|
[4] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 3. |
704023
|
[4] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 4. |
7796378
|
[1] |
PUMP
|
HFI
- hydraulic (Includes key) Superseded by part number: 87448820
|
| 5. |
703199
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
|
CAS
3/8-16 X 3/4 C
|
| 6. |
77016
|
[1] |
LUBE NIPPLE
|
IH
1/4-28 STRAIGHT ZERK Superseded by part number: 87414
|
| 7. |
740803
|
[1] |
BUSHING
|
CAS
- oilite
|
| 8. |
700112190
|
[1] |
ARM
|
CAS
- idler (Includes item 7)
|
| 9. |
700112189
|
[1] |
BUSHING
|
CAS
|
| 10. |
853317
|
[1] |
FRONT IDLER
|
CAS
IDLER - flat
|
| 11. |
7701949
|
[1] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
5/8-11 X 2 C Superseded by part number: 86505999
|
| 12. |
705061
|
[1] |
PLUG
|
NNA
5/8" Superseded by part number: 492-11062
|
| 13. |
704130
|
[1] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
| 14. |
69187
|
[2] |
SET SCREW,Sq Hd, 5/16"-18 x 1"
|
CAS
5/16-18 X 1 CPSQHSS Superseded by part number: 88971
|
| 15. |
1662626
|
[1] |
SHEAVE
|
CAS
- drive, pump
|
| 16. |
7702038
|
[1] |
SCREW,Hex, 1/2" - 13 x 3", Gr 5
|
CAS
1/2-13 X 3 C Superseded by part number: 87339
|
| 17. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 18. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 19. |
86516876
|
[1] |
1/2-13 H
|
COVER
|
| 20. |
700121576
|
[1] |
LARGE PLATE
|
CAS
PLATE WA - front
|
| 21. |
700121578
|
[1] |
LARGE PLATE
|
CAS
PLATE WA - pump, rear
|
