纽荷兰零件查询(DC95) - CRAWLER DOZER (8/04-) (03-03) - CONTROLS, THROTTLE - LINKAGE AT ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
552 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79083370 | [1] | QUICK MALE COUPLING | LEC |
| 2. | 402749A1 | [1] | BALL JOINT | CASFemale - RH |
| 3. | 87434963 | [1] | CONNECTING ROD | BURDecelerator |
| 4. | 87449800 | [1] | LEVER | BURLever Superseded by part number: 87327150 |
| 5. | 627-6016 | [2] | BOLT,Hex, M6 x 1 x 16mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86639037 |
| 6. | 614-10035 | [1] | BOLT,Hex, M10 x 1.5 x 35mm, Cl 8.8, Full Thd | CASM10 x 35 Superseded by part number: 9706704 |
| 7. | 47335444 | [2] | NUT | NHM10 Superseded by part number: 934300R1 |
| 8. | 832-10410 | [1] | NUT,M10 x 1.5, Cl 8 | CAS Superseded by part number: 190003888452 |
| 9. | 895-11006 | [2] | WASHER,M6 x 12mm OD x 1.6mm | CAS Superseded by part number: 86588450 |
| 10. | 895-11010 | [3] | WASHER,11mm ID x 20mm OD x 2mm Thk | CAS Superseded by part number: 14496621 |
