纽荷兰零件查询(DC95) - CRAWLER DOZER (8/04-) (03-10) - FUEL FILTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
223 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852750 | [1] | FUEL FILTER | TORDual Assy Superseded by part number: |
| 2. | 2852352 | [1] | SUPPORT | TOR |
| 3. | 2852134 | [2] | FLANGE BOLT,Hex, M12 x 1.75 x 25mm | TOR Superseded by part number: 16677735 |
| 4. | 2852355 | [2] | SCREW | TORFlange, M10 x 25 Superseded by part number: 16587125 |
| 5. | 4893833 | [2] | HYD CONNECTOR | TOR10v 1.5 |
| 6. | 4858608 | [2] | SEAL,14mm ID x 19.50mm OD x 1.50mm Thk | TTF Superseded by part number: 2852356 |
| 7. | 87803192 | [2] | FUEL FILTER | PAElement Superseded by part number: 84565884 |
