凯斯零件查询(8520) - CASE IH RECTANGULAR BALER (1/88-12/99) (3-02) - PICKUP FRAME AND WRAPPER ASSEMBLY - LEFT, (8520 ONLY) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
292 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
061424
|
[1] |
1/4 X 1/4 X 1-1/4 GIB KEY
|
|
| 2. |
700112388
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET 40B50
|
| 3. |
050534
|
[2] |
FLANGE - bearing
|
|
| 4. |
700708094
|
[1] |
SPHERICAL BEARING,1.25" ID x 62 mm OD x 35.71 mm
|
CAS
BEARING - spherical Superseded by part number: 2419CHA
|
| 5. |
703132
|
[21] |
SERRATED SCREW
|
CAS
5/16-18 X 3/4 HFSS Superseded by part number: 145913
|
| 6. |
700013
|
[23] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 X 3/4 RHSNB
|
| 7. |
705020
|
[23] |
LOCK WASHER
|
CAS
5/16" Superseded by part number: 492-11031, 492-11031, NLS
|
| 8. |
704015
|
[23] |
NUT,5/16"-18, G5
|
CAS
5/16-18 H Superseded by part number: 425-105, 425-105, 9635082
|
| 9. |
700112389
|
[1] |
SHIELD
|
CAS
WRAPPER - end
|
| 10. |
700112379
|
[21] |
GUARD
|
IH
WRAPPER
|
| 11. |
7700065
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| 12. |
705038
|
[3] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 13. |
704023
|
[3] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 14. |
700112364
|
[1] |
FRAME
|
HFI
WA - pickup
|
| 15. |
7870165
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2", Gr 5
|
CAS
5/8-11 X 2 RHSNB Superseded by part number: 280742
|
| 16. |
705061
|
[1] |
PLUG
|
NNA
5/8" Superseded by part number: 492-11062
|
| 17. |
704130
|
[1] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
| 18. |
700115572
|
[1] |
SQ HOLE WASHER
|
CAS
- spherical
|
| 19. |
052233
|
[2] |
5/8 x 14 GAUGE NRMB
|
|
| 20. |
047977
|
[1] |
SPROCKET - idler
|
|
