凯斯零件查询(8520) - CASE IH RECTANGULAR BALER (1/88-12/99) (7-04) - WHEEL AND HUB ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
220 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
13542
|
[10] |
WHEEL BOLT,Hex, 9/16" - 18 x 1 1/8", HT
|
NH
9/16-18 X 1-1/8 WHEEL BOLT Superseded by part number: 86628557
|
| 2. |
700707956
|
[2] |
WHEEL
|
L
- 15 x 6 inch (8520 std)
|
| . . |
700707949
|
[2] |
RIM
|
CAS
WHEEL - 14 x 8 inch (8530 & 8520 flotation)
|
| 3. |
T27814
|
[2] |
CAP
|
CAS
- hub Superseded by part number: 200734
|
| 4. |
704346
|
[2] |
BRACKET
|
IH
1-14 SLOTTED HEX JAM NUT Superseded by part number: 129-270, 129-270, NLS
|
| 5. |
700708092
|
[2] |
ROLLER BEARING
|
CAS
CONE - bearing, outer Superseded by part number: E13994
|
| 6. |
50104
|
[2] |
BEARING CUP,50.01mm OD
|
CAS
CUP - bearing, outer
|
| 7. |
710459
|
[2] |
CUP
|
CAS
- bearing, inner
|
| 8. |
710475
|
[2] |
ROLLER BEARING
|
CAS
CONE - bearing, inner Superseded by part number: 618023R91
|
| 9. |
844571
|
[2] |
SEAL
|
L
- grease Superseded by part number: 678620
|
| 10. |
700112510
|
[2] |
SPINDLE
|
CAS
WA
|
| 11. |
6280788
|
[2] |
HUB
|
L
(Includes items 6 and 7)
|
| 12. |
432-824
|
[2] |
COTTER PIN,1/8" x 1 1/2"
|
CAS
1/8 X 1-1/2 COTTER PIN Superseded by part number: 80708
|
| 13. |
827402
|
[2] |
VALVE
|
IH
STEM - valve (Used with 700710949 wheel)
|
| . . |
A38261
|
[2] |
VALVE
|
CAS
STEM - valve (Used with 700707956 wheel) Superseded by part number: 196033
|
| 14. |
7701949
|
[8] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
5/8-11 X 2 C Superseded by part number: 86505999
|
| 15. |
705061
|
[8] |
PLUG
|
NNA
5/8" Superseded by part number: 492-11062
|
| 16. |
704130
|
[8] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
