神钢零件查询(F4HFE6137 B003) - ENGINE 5801925169 47748446 TC 5.80 TIER 4B (1/12-) (10.001.AB[01]) - CRANKCASE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
831 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504288602 | [1] | ASSY, Incl 9 - 15, 21 | |
| 2. | 4895605 | [2] | HEX SOCKET PLUG,M14 x 1.5 | TORASSY, Incl 3, 22 |
| 3. | 4899115 | [2] | O-RING,2.2mm Thk x 11.3mm ID | TOR |
| 4. | 4899009 | [2] | PLUG,M10 x1 | TORASSY, Incl 5, 23 |
| 5. | 4899072 | [2] | O-RING,1.6mm Thk x 8.1mm ID | TOR |
| 6. | 4895392 | [2] | HEX SOCKET PLUG,M18 x 1.5 | TORASSY, Incl 7, 20 |
| 7. | 4895393 | [2] | O-RING,2.2mm Thk x 15.3mm ID | TOR |
| 8. | 4895049 | [2] | DOWEL,M16.05 x 10 | TOR |
| 9. | NSS | [6] | NOT SOLD SEPARAT | CONBearing, Incl in 1 |
| 10. | 4899026 | [14] | DOWEL,M18 x 10 | TOR |
| 11. | 4895039 | [3] | EXPANSION PLUG,M17.73 | TOR |
| 12. | 4895038 | [6] | EXPANSION PLUG,M58.06 | TOR |
| 13. | 4895228 | [3] | EXPANSION PLUG,35.23mm x 7.94mm | TOR |
| 14. | 4891353 | [4] | SCREW,Flg Hd, M12 x 1.5 x 120 | TOR |
| 15. | 4895040 | [2] | BUSHING,54.39mm ID x 59.39mm OD x 25.4mm L | TOR |
| 16. | 4899803 | [2] | TAPPET | TOR Superseded by part number: 4891226 |
| 17. | NSS | [6] | NOT SOLD SEPARAT | CONOil nozzle, Incl in 19 |
| 18. | 5801639154 | [6] | SCREW | TOR |
| 19. | 504047260 | [6] | LUBE OIL NOZZLE | TORASSY, Incl 17, 18 Superseded by part number: 5801910166 |
| 20. | NSS | [2] | NOT SOLD SEPARAT | CONPlug, Incl in 6 |
| 21. | NSS | [1] | NOT SOLD SEPARAT | CONCrankcase, Incl in 1 |
| 22. | NSS | [2] | NOT SOLD SEPARAT | CONPlug, Incl in 2 |
| 23. | NSS | [2] | NOT SOLD SEPARAT | CONPlug, Incl in 4 |
