凯斯零件查询(8530) - CASE IH RECTANGULAR BALER (1/88-12/99) (9-16) - HYDRAULIC PICKUP LIFT KIT, (HK40422 HYDRAULIC PICKUP LIFT KIT COMPLETE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
496 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
HK40422
|
[1] |
HYDRAULIC PICKUP LIFT KIT COMPLETE
|
|
| 1. |
7721798
|
[3] |
CABLE
|
CAS
TIE - cable
|
| 2. |
700704629
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 3. |
7898737
|
[1] |
CLAMP
|
CAS
- hose Superseded by part number: 9827902
|
| 4. |
703199
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
|
CAS
3/8-16 X 3/4 C
|
| 5. |
704247
|
[1] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| 6. |
7046063
|
[1] |
ELBOW
|
CAS
90 DEGREE ELBOW (With .06 orifice)
|
| 7. |
846170
|
[1] |
ELBOW
|
CAS
90 DEGREE ELBOW Superseded by part number: 578384
|
| 8. |
700115583
|
[1] |
BUSHING
|
CAS
|
| 9. |
62174
|
[2] |
PIN
|
CAS
5/32 X 1 COTTER PIN Superseded by part number: 83903970
|
| 10. |
700115585
|
[1] |
ARM/LIFTING DEVICE
|
HFI
ARM - mounting, cylinder
|
| 11. |
63693
|
[1] |
PIN
|
CAS
5/8 X 2 CLEVIS PIN
|
| 12. |
7770738
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 3 1/2", Gr 5
|
CAS
1/2-13 X 3-1/2 RHSNB Superseded by part number: 111-505
|
| 13. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 14. |
86516876
|
[1] |
1/2-13 H
|
COVER
|
| 15. |
700116648
|
[1] |
PIN
|
CAS
|
| 16. |
7075625
|
[1] |
CYLINDER
|
L
- hydraulic Superseded by part number: 700726495
|
| 17. |
705632
|
[1] |
WASHER
|
CAS
5/8 NARROW PLAIN WASHER Superseded by part number: 495-11066, 495-11066, 87365
|
