700122628
|
[1] |
KIT
|
HFI
HYDRAULIC PUMP CONVERSION KIT COMPLETE
|
| 1. |
700701905
|
[1] |
SCREW,Cross Pan Hd, 3/8"-16 x 3/4"
|
CAS
3/8-16 X 3/4 CRPHMS
|
| 2. |
705533
|
[1] |
WASHER
|
NNA
3/8 HARDENED PLAIN WASHER Superseded by part number: 496-11041, 496-11041, 80702
|
| 3. |
705038
|
[1] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 4. |
704023
|
[1] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 5. |
703132
|
[1] |
SERRATED SCREW
|
CAS
5/16-18 X 3/4 HFSS Superseded by part number: 145913
|
| 6. |
751628
|
[1] |
CLAMP
|
CAS
- line Superseded by part number: 675162
|
| 7. |
700709945
|
[1] |
HYDRAULIC HOSE,12.70 mm ID x 1352.00 mm, SAE 100R2
|
CAS
(Includes item 8) 12.70 mm ID x 1352.00 mm, SAE 100R2
|
| 8. |
738450
|
[4] |
O-RING
|
CAS
Superseded by part number: 167269
|
| 9. |
7791460
|
[1] |
INSERT
|
HFI
- hose (Includes item 10) Superseded by part number: 217-390
|
| 10. |
738484
|
[1] |
O-RING
|
IH
Superseded by part number: 167266
|
| 11. |
700709946
|
[1] |
HOSE
|
CAS
- hydraulic, section
|
| 12. |
704734
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 13. |
700121512
|
[1] |
SUPPORT
|
CAS
- tank, front
|
| 14. |
7883382
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 X 1 HWHMS Superseded by part number: 87034804
|
| 15. |
704247
|
[6] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| 16. |
7720055
|
[2] |
HOSE CLAMP
|
CAS
CLAMP - hose Superseded by part number: 507586
|
| 17. |
755769
|
[5] |
CLAMP
|
HFI
- hose Superseded by part number: 87029955
|
| 18. |
700121513
|
[1] |
SUPPORT
|
CAS
- tank, rear
|
| 19. |
827717
|
[1] |
GROMMET
|
CAS
- rubber
|
| 20. |
700121573
|
[2] |
BEARING LINER
|
CAS
LINER - reservoir
|
| 21. |
700709759
|
[1] |
RESERVOIR ASSY.
|
CAS
RESERVOIR - oil
|
| 22. |
700709944
|
[2] |
STRAP
|
CAS
- reservoir
|
| 23. |
700710340
|
[1] |
CABLE
|
CAS
- control
|
| 24. |
7701964
|
[2] |
SCREW,Hex, 1/4" - 20 x 2 1/2", Gr 5
|
L
1/4-20 X 2-1/2 C Superseded by part number: 87845
|
| 25. |
705517
|
[2] |
WASHER
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 496-11028, 496-11028, 70900816
|
| 26. |
705012
|
[2] |
LOCK WASHER
|
CAS
1/4" Superseded by part number: 492-11025, 492-11025, 86517257
|
| 27. |
704007
|
[2] |
NUT,1/4"-20, G5
|
CAS
1/4-20 H Superseded by part number: 7770
|
| 28. |
7846108
|
[1] |
HYD CONNECTOR,3/4"-14 NPTF
|
CAS
NIPPLE - male Superseded by part number: 217-1073
|
| 29. |
7846124
|
[1] |
TEE
|
CAS
- swivel
|
| 30. |
7700065
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| 31. |
700709941
|
[1] |
HYDRAULIC HOSE,12.70 mm ID x 2600.00 mm, SAE 100R1
|
CAS
12.70 mm ID x 2600.00 mm, SAE 100R1
|
| 32. |
700709942
|
[1] |
HYDRAULIC HOSE,12.70 mm ID x 2600.00 mm, SAE 100R2
|
CAS
12.70 mm ID x 2600.00 mm, SAE 100R2
|
| 33. |
88902
|
[1] |
NUT,3/8"-16
|
NH
3/8-16 HCLN
|
| 34. |
451641
|
[1] |
CLAMP
|
CAS
- hose
|
| 35. |
7041932
|
[1] |
ROD, CONNECTING
|
CAS
CONNECTOR
|
| 36. |
1661479
|
[1] |
ARM
|
CAS
- control
|
| 37. |
700709943
|
[1] |
ADAPTER
|
CAS
- male (Includes item 8)
|
| 38. |
7883374
|
[2] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 255918
|
| 39. |
700121572
|
[1] |
SUPPORT
|
CAS
- plate, valve
|
| 40. |
700121571
|
[1] |
SUPPORT
|
CAS
ANGLE - support, valve
|
| 41. |
7046501
|
[1] |
ELBOW
|
CAS
90 DEGREE ELBOW (Includes item 8) Superseded by part number: 218-5121, 218-5121, 9617891
|
| 42. |
7792377
|
[1] |
ELBOW
|
HFI
45 DEGREE ELBOW (Includes item 8) Superseded by part number: 330345
|
| 43. |
7796394
|
[1] |
VALVE
|
CAS
- flow control
|
| 44. |
1661297
|
[1] |
MOUNTING PARTS
|
CAS
MOUNTING - valve
|
| 45. |
8797433
|
[1] |
CLAMP
|
CAS
|
| 46. |
413-48
|
[1] |
BOLT,Hex, 1/4" - 20 x 1/2", Gr 5
|
CAS
1/4-20 X 1/2 C Superseded by part number: 88542
|
| 47. |
704221
|
[1] |
NUT
|
NNA
1/4-20 HFSLN Superseded by part number: 231-5144, 231-5144, 523282
|
