神钢零件查询(F4HFE6137 B003) - ENGINE 5801925169 47748446 TC 5.80 TIER 4B (1/12-) (55.010.AA) - WIRE HARNESS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
942 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | NS | [2] | NOT SERVICED | BASClamp |
| 3. | NS | [3] | NOT SERVICED | BASNut |
| 4. | 47401109 | [3] | WIRE HARNESS | BRR |
| 4. | 4896052 | [3] | WIRE HARNESS | TOR Superseded by part number: 5801567608 |
| 4. | 504039152 | [3] | ELECTRIC CABLE | SM Superseded by part number: 5801567608 |
| 5. | 2852776 | [3] | WASHER,6mm ID x 11mm OD | TOR Superseded by part number: 17094614 |
| 5. | 17094614 | [3] | WASHER | LEC Superseded by part number: 4895421 |
| 6. | 2852602 | [3] | HEX SOC SCREW,M6 x 16mm | SM Superseded by part number: 16689121 |
| 6. | 16689121 | [3] | SCREW,Skt Hd, M6 x 16mm | TOR Superseded by part number: 4895427 |
