纽荷兰零件查询(FD145) - CRAWLER DOZER (N.A. VERSION) (10/98-) (9.441[07]) - ALL HYDRAULIC VERSION - HYDR. SYSTEM - OPTIONAL CODE 76048220 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
852 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8280835 | [2] | RING | LEC |
| 2. | 79037560 | [1] | SPHERICAL BEARING,35 mm ID x 72 mm OD x 39 mm | LEC- IN ALTERNATIVE Superseded by part number: 79036604 |
| 2. | 79036604 | [1] | SPHERICAL BEARING,35mm ID x 72mm OD x 39mm W | LEC- IN ALTERNATIVE |
| 3. | 14465780 | [1] | O-RING,0.139" Thk x 3.609" ID, -239, Cl 5, 75 Duro | BHB(M91.67 ID x 3.53 Thk) Superseded by part number: |
| 4. | 79071319 | [1] | GASKET | LEC Superseded by part number: 79065562, 79065561, 79065560 |
| 5. | 71449083 | [1] | ROD | LEC |
| 6. | 71400744 | [1] | BASE PLATE | LEC |
| 7. | 8297295 | [1] | RING,73.8mm ID x 80mm OD x 1.5mm Thk | BHB |
| 8. | 14465480 | [1] | O-RING,0.139" Thk x 3.234" ID, -236, Cl 5, 75 Duro | LEC2,62X72,69 Superseded by part number: 83911410, 510137 |
| 9. | 13407211 | [2] | LUBE NIPPLE,M10 x 1 | TTF Superseded by part number: 84351730 |
| 10. | 71449081 | [1] | ENGINE CYLINDER LINER | LEC- LEFT |
| 10. | 71449091 | [1] | BARREL | LEC- RIGHT |
| 11. | 79103511 | [1] | PLATE | LEC |
| 12. | 71449082 | [1] | PISTON | LEC |
| 13. | 79103508 | [1] | SEAL | LEC |
| 14. | 79102183 | [1] | NUT | LEC |
| 15. | 79099830 | [1] | SET SCREW,less Hex Socket, M10 x 1.5 x 10mm | LEC |
