神钢零件查询(F4HFE6137 B003) - ENGINE 5801925169 47748446 TC 5.80 TIER 4B (1/12-) (55.202.AA) - MANIFOLD, HEATER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
357 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2854700 | [1] | COVER | TOR Superseded by part number: 504114351 |
| 1. | 504114351 | [1] | COVER | TOR Superseded by part number: 2854700 |
| 2. | 2854701 | [1] | GASKET,0.8mm Thk | TOR Superseded by part number: 504114491 |
| 2. | 504114491 | [1] | GASKET | TOR Superseded by part number: 2854701 |
| 3. | 2854702 | [6] | SCREW,Hex Flg, M6 x 20mm | TOR Superseded by part number: 16585870 |
| 3. | 16585870 | [6] | SCREW,Hex, M6 x 20mm | TOR |
