凯斯零件查询(8530) - CASE IH RECTANGULAR BALER (1/88-12/99) (6-14) - FINGER (TWINE) GUIDE ASSEMBLY, (S.N. CFH0018717 AND LATER), (S.N. CFH0020517 AND LATER) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
550 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7700065
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| 2. |
704247
|
[2] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| 3. |
700047
|
[2] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 4. |
705038
|
[2] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 5. |
704023
|
[2] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 6. |
703579
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd
|
CAS
5/16-18 X 1 C
|
| 7. |
705525
|
[2] |
WASHER
|
CAS
5/16 HARDENED PLAIN WASHER Superseded by part number: 86637953
|
| 8. |
231-4115
|
[2] |
NUT,5/16"-18, GB
|
CAS
5/16-18 HTLN GR/C CW Superseded by part number: 280736
|
| 9. |
80702
|
[4] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 HARDENED PLAIN WASHER
|
| 10. |
700703692
|
[3] |
ADJUSTMENT ROD
|
L
ROD - end
|
| 11. |
704429
|
[2] |
NUT
|
CAS
5/16-24 H Superseded by part number: 86629539
|
| 12. |
700119462
|
[2] |
ROD
|
IH
|
| 13. |
7884414
|
[2] |
CAPSCREW,Button Hd, 3/8" - 16 x 1", Gr 8
|
CAS
3/8-16 HSBHCS
|
| 14. |
704734
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 15. |
700119459
|
[2] |
MOUNTING PARTS
|
CAS
MOUNTING - finger
|
| 16. |
700120654
|
[2] |
FINGER
|
IH
ASSEMBLY - twine (Includes items 10 & 18)
|
| 17. |
6553614
|
[2] |
SPACER
|
CAS
|
| 18. |
700709157
|
[1] |
RIVET
|
CAS
5/16 X 3/4 RIVET - flat
|
