神钢零件查询(F4HFE6138 A002) - ENGINE - 5801448559 - 84312222 (1/10-) (10.218.AI[01]) - INJECTION PIPE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
633 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2859144 | [1] | MANIFOLD | BHBASSY, Incl 2 - 4 Superseded by part number: |
| 2. | 2854541 | [1] | ACCUMULATOR | TOR Superseded by part number: |
| 3. | 2854543 | [1] | VALVE PRESSURE RELIE | TOR |
| 4. | 2859145 | [1] | SENSOR | TOR Superseded by part number: |
| 5. | 2857017 | [3] | PIPE | TOR Superseded by part number: |
| 6. | 2857046 | [3] | PIPE | TOR Superseded by part number: |
| 7. | 2857048 | [1] | PIPE | TORASSY, Incl 8 - 11, 13 Superseded by part number: |
| 8. | 2855127 | [1] | CLAMP BRACKET | TOR |
| 9. | 2854556 | [2] | CLAMP BRACKET | TOR |
| 9. | 2854558 | [1] | RUBBER SEAL | TOR |
| 10. | 2854557 | [2] | CLAMP BRACKET | TOR |
| 11. | 2854559 | [2] | SCREW | TOR Superseded by part number: |
| 12. | 2853537 | [4] | BOLT,Hex Flange Head Cap M8 x 1.25 x 125mm | TOR Superseded by part number: 504053874 |
| 13. | 4896884 | [1] | BOLT,Flng, M8 x 1.25 x 16mm, Cl 10.9 | TORM8 x 1.25 x 16 |
