凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (57) - DENSITY, REDUCER, BALE KIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
690 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
HK42373
|
[1] |
DENSITY (reducer) BALE KIT COMPLETE
|
|
| 1. |
700101177
|
[1] |
ANGLE
|
HFI
FILLER - angle, left
|
| 2. |
700101229
|
[1] |
PLATE
|
HFI
FILLER - plate, lower
|
| 3. |
700101176
|
[1] |
ANGLE
|
HFI
FILLER - angle, right
|
| 4. |
700101233
|
[2] |
PLATE
|
HFI
FILLER - chamber, side
|
| 5. |
700101232
|
[2] |
PLATE
|
HFI
FILLER - plate, top
|
| . . |
700054
|
[16] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 x 1-1/4 round head square neck bolt grade 5 Superseded by part number: 86508773
|
| . . |
61-42512
|
[3] |
HEX SOC SCREW,Flat Hd, 1/4"-20 x 3/4"
|
CAS
1/4-20 x 3/4 hex socket flat countersunk head cap screw
|
