| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
403-02392
|
[1] |
SEAL KIT
|
|
| -. |
2190-3247
|
[-] |
NAME PLATE ASS'Y
|
|
| 1. |
2190-3249
|
[2] |
NAME;PLATE
|
|
| 1. |
2190-3576
|
[2] |
NAME;PLATE
|
|
| 10. |
2190-2475
|
[1] |
PLATE;NAME
|
|
| 11. |
2190-2635
|
[1] |
PLATE;NAME(BOOM SWING)
|
|
| 12. |
2190-2436
|
[1] |
NAME;PLATE
|
|
| 13. |
2190-2437
|
[1] |
NAME;PLATE
|
|
| 14. |
2190-1921D86
|
[1] |
NAME;PLATE
|
|
| 15. |
2190-2446
|
[1] |
PLATE;NAME(FUEL)
|
|
| 16. |
2190-2890
|
[1] |
PLATE;NAME
|
2190-2890A
|
| 16. |
2190-2890A
|
[1] |
PLATE;NAME
|
|
| 17. |
2122-1002D1
|
[4] |
RIVET
|
2122-1002D2
|
| 17. |
2122-1002D2
|
[4] |
RIVET
|
|
| 18. |
2190-2438A
|
[1] |
LABEL
|
|
| 19. |
2190-2638
|
[1] |
NAME;PLATE,SWING LOCK
|
|
| 2. |
2190-2747
|
[2] |
NAME;PLATE
|
2190-2745
|
| 2. |
2190-2745
|
[2] |
NAME;PLATE
|
|
| 2. |
2190-3385D10
|
[3] |
NAME;PLATE
|
|
| 20. |
2190-2503
|
[1] |
LABEL
|
|
| 22. |
2190-2314D1
|
[2] |
TAPE;ANTI-SKID
|
|
| 23. |
2190-1122A
|
[1] |
LABEL
|
|
| 24. |
2190-2633
|
[1] |
PLATE;NAME
|
|
| 25. |
2190-2571
|
[1] |
LABEL
|
|
| 26. |
2190-3257
|
[1] |
LABEL
|
|
| 27. |
2190-2573
|
[1] |
LABEL,HOT WATER
|
|
| 28. |
2190-3250
|
[1] |
NAME;PLATE
|
2190-3250A
|
| 28. |
2190-3250A
|
[1] |
NAME;PLATE
|
|
| 3. |
2190-2433B
|
[1] |
NAME;PLATE
|
|
| 30. |
2190-3341
|
[1] |
LABEL
|
2190-3341A
|
| 30. |
2190-3341A
|
[1] |
LABEL
|
|
| 31. |
2190-3203
|
[1] |
LABEL
|
|
| 32. |
2190-3204
|
[1] |
LABEL
|
|
| 33. |
2190-3205
|
[1] |
LABEL
|
|
| 34. |
2190-3206
|
[1] |
LABEL
|
|
| 35. |
2190-3207
|
[1] |
LABEL
|
|
| 36. |
2190-3208
|
[1] |
LABEL
|
|
| 37. |
2190-3209
|
[1] |
LABEL
|
|
| 38. |
2190-3575
|
[2] |
NAME;PLATE
|
|
| 4. |
2190-2434B
|
[1] |
NAME;PLATE
|
|
| 5. |
2190-2435B
|
[1] |
NAME;PLATE
|
|
| 6. |
2190-2628
|
[1] |
NAME;PLATE, JOYSTICK
|
|
| 7. |
2190-2629
|
[1] |
NAME;PLATE, JOYSTICK
|
|
| 8. |
2190-2637
|
[1] |
NAME;PLATE, TRAVEL
|
|
