凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (47) - LIGHT KIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
248 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
HK42366
|
[1] |
LIGHT KIT COMPLETE
|
|
| 1. |
2700179
|
[1] |
ELECTRICAL WIRE
|
CAS
WIRING HARNESS
|
| 2. |
2700178
|
[1] |
HARNESS
|
HFI
WIRING HARNESS
|
| 3. |
41137
|
[1] |
SWITCH
|
CAS
light Superseded by part number: 041137
|
| 4. |
2700174
|
[1] |
ELECTRICAL WIRE
|
HFI
WIRING HARNESS
|
| 5. |
2401523
|
[2] |
BRACKET
|
HFI
lamp
|
| 6. |
CAS41624
|
[3] |
LAMP
|
CAS
(12-V, 35-watt, seal beam)
|
| 7. |
722470
|
[2] |
MOUNTING CLIP
|
CAS
CABLE TIE Superseded by part number: 529070
|
| 8. |
751628
|
[17] |
CLAMP
|
CAS
line Superseded by part number: 675162
|
| 9. |
1702364
|
[1] |
FUSE
|
HFI
15 AMP Superseded by part number: 590420
|
| . . |
7700065
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 round head square neck bolt grade 5 Superseded by part number: 280430
|
| . . |
7703432
|
[2] |
BOLT,Hex, Serr, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 hex flange serrated screw Superseded by part number: 255918
|
| . . |
7883325
|
[3] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 hex washer head machine screw Superseded by part number: 121-115
|
