| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700704934
|
[1] |
CYLINDER
|
CAS
SHOWN Superseded by part number: 700711078, 700711032
|
| 1. |
700704936
|
[1] |
SLEEVE CYLINDER
|
CAS
BARREL
|
| 2. |
700704938
|
[1] |
LOCK NUT
|
CAS
LOCK NUT
|
| 3. |
700704942
|
[1] |
PISTON
|
CAS
|
| 4. |
700704935
|
[1] |
BUSHING
|
CAS
BEARING
|
| 5. |
700704939
|
[1] |
RETAINER
|
CAS
|
| 6. |
700704937
|
[1] |
ROD
|
CAS
- piston
|
| . . |
700704941
|
[1] |
SEAL KIT
|
CAS
O-ring and seal repair kit, Includes items in art marked with aterisk.
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
1/4-20 x 1/4 cone point hex socket set screw
|
