神钢零件查询(F4HFE6138 A002) - ENGINE - 5801448559 - 84312222 (1/10-) (55.015.AA) - ENGINE, CONTROL, UNIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
613 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2854594 | [1] | ECU | TOR Superseded by part number: 504122542 |
| 1. | 2854594R | [1] | REMAN-MODULE | MKTReman for New PN 2854594 Superseded by part number: 504122542R |
| 1. | 2854594C | [1] | CORE-MODULE | MKTReturn Number Superseded by part number: |
| 2. | 4899057 | [1] | FLANGE NUT,M6 | TORM6 x 1.0 |
| 3. | 2854593 | [1] | STUD | TOR Superseded by part number: 16727824 |
| 4. | 2852825 | [1] | PLUG,100mm x 40mm L | TOR |
| 5. | 4899078 | [3] | SCREW,Hex Flg, M8 x 1.25 x 45 | TORM8 x 1.25 x 45 |
| 6. | 2852818 | [7] | SCREW,Hex, M6 x 1 x 30mm | SMM6 x 1 x 30 Superseded by part number: 16586025 |
| 7. | 2854595 | [1] | BRACKET | TORASSY, Incl 8 - 13 Superseded by part number: 98498817, 504070042, 4896542, 4890964, 10298460 |
| 8. | 2854596 | [1] | BRACKET | TOR Superseded by part number: |
| 10. | 4858608 | [2] | SEAL,14mm ID x 19.50mm OD x 1.50mm Thk | TTF Superseded by part number: 2852356 |
| 11. | 4890964 | [1] | FITTING,M12 x 1.5 | TOR |
| 12. | 4896542 | [1] | HYD CONNECTOR,M12 x 1.5 ORB x 6 ORFS | TOR |
| 13. | 2855150 | [6] | INSULATOR BLOCK | TOR Superseded by part number: 98498817 |
